They are used for therapeutic administration of infusion solutions from bottles (bags) by gravity or using infusion pumps INFUSOMAT P, ARGUS 707, A400, A404, A414, VOLUMED µVP5005 .
The products have a drop chamber with a ring for fitting in optical drop sensor, 15 µm infusion filter, vented spike with hydrophobic bacterial filter, flow controller (clamp with wheel), transparent PVC tube 3.0/4.1 mm and positive connection cone Male Luer Lock.
Infusion set IS-127 P PVC tube DEHP-free, diameter 3/4.1 mm, length 1500 mm. Transparent piercing spike, dimensions according to ČSN EN ISO 8536-4. Aerator with 3 µm hydrophobic bacterial filter to prevent penetration of microorganisms. Transparent drop chamber PVC DEHP-free, featuring a mark for setting up of the maximum level of liguid, and a ring for fitting in optical drop sensor. 15 µm liquid filter to capture solid particles. Flow controller with a holder for fixing the ending piece of the set (solution to "Spaghetti syndrome"). Male Luer lock connector with thread according to ČSN EN 1707. Safe and easily removable cover of the piercing spike and connector for maintaining sterility.
Infusion set IS-127 P 180 cm PVC tube DEHP-free, diameter 3/4.1 mm, length 1800 mm. Transparent piercing spike, dimensions according to ČSN EN ISO 8536-4. Aerator with 3 µm hydrophobic bacterial filter to prevent penetration of microorganisms. Transparent drop chamber PVC DEHP-free, featuring a mark for setting up of the maximum level of liguid, and a ring for fitting in optical drop sensor. 15 µm liquid filter to capture solid particles. Flow controller with a holder for fixing the ending piece of the set (solution to "Spaghetti syndrome"). Male Luer lock connector with thread according to ČSN EN 1707. Safe and easily removable cover of the piercing spike and connector for maintaining sterility.
